EZVIZ CAMERA CS-H6 5MP WIFI IN DOOR

EZVIZ CAMERA CS-H6 5MP WIFI IN DOOR

Estimated reading time: 3 minutes

• High-resolution image sensor for crisp visuals
• AI-powered smart detection features
• Two-way audio communication capability
• IR night vision for low-light security
• Fast and easy installation with included accessories

EZVIZ CAMERA CS-H6 5MP WIFI IN DOOR quantity Add to cart
You have the right to request a return of the product within 3 days of receiving the order if there is a defect or manufacturing issue with the product – Terms and Conditions apply
Delivery within 1 to 2 days.

Model: CS-H6-R100-1J5WF
Camera:
Image Sensor: 1/2.7″ Progressive Scan CMOS
Shutter Speed: Self-adaptive shutter
Lens: 4mm@ F1.6, view angle:87° (Horizontal), 53° (Vertical), 104°(Diagonal)

PT Angle: Pan: 353° , Tilt: 133°
Minimum Illumination: 0.51Lux @(F1.6, AGC ON), 0 Lux with IR
Lens Mount: M12
Day & Night: IR-cut filter with auto-switching
DNR: 3D DNR
WDR: Digital WDR
BLC: Supports
Night Vision: 10 m
Max. Resolution: 2880 × 1620
Frame Rate: Max:25fps; Self-Adaptive during network transmission
Video Compression: H.265 / H.264

For more detailed specifications, see the camera specifications.
Video Bit Rate: Ultra-HD; HD; Standard. Adaptive bit rate.
Audio Bit Rate: Self-Adaptive
Max. Bitrate: 4 Mbps
Wi-Fi Standard: IEEE802.11a, 802.11b, 802.11g, 802.11n, 802.11ac
Frequency Range: 2.4G: 2400~2483.5 MHz 5G: 5170~5250 MHz, 5735~5835 MHz
Channel Bandwidth: Supports 40 MHz
Security: 64 / 128-bit WEP, WPA / WPA2, WPA-PSK / WPA2-PSK

Transmission Rate: 11b 11Mbps, 11g 54Mbps, 11nHT20 MCS7, 11nHT40 MCS7; 11a 54Mbps, 11nHT20 MCS7, 11nHT40 MCS7
Wi-Fi Pairing: AP pairing
Protocol: EZVIZ Cloud Proprietary Protocol
Interface Protocol: EZVIZ Cloud Proprietary Protocol
Wired Network: RJ45 × 1 (10M / 100M Adaptive Ethernet Port)
Local Storage: Micro SD card slot (Max. 512G)
Cloud Storage: EZVIZ Cloud Storage
Smart Alarm: AI-Powered Human Shape Detection / Pet Detection / Waving-Hand Detection / Voice Activity Detection

For details on smart features, refer to our page on smart alarm systems.
Customized Alert Area: Supports
Two-Way Talk: Supports ( Double Mic )
General Function: Anti-Flicker, Dual-Stream, Heart Beat, Mirror Image, Password Protection, Watermark
Operating Conditions: -10°C to 45°C ( 14°F to 113 °F ), humidity 95% or less (non-condensing)

Power Supply: DC 5V/2A（Type-C)
Power Consumption: Max. 8W
Product Dimensions: 115.5 × 116 × 160 mm (4.55 × 4.57 × 6.30 inch)
Packaging Dimensions: 116 × 116 × 164 mm (4.57 × 4.57 × 6.46 inch)
Weight (With Package): 487 g (17.18 oz)
Net Weight: 255 g (8.99 oz)

In the box:
– H6 Camera
– Base
– Power Cable
– Power Adapter
– Drill Template
– Screw Kit
– Quick Start Guide
– Regulatory Information

For additional setup tips, have a look at our article on camera setup tips.
