| Power Generation Department |
| Power generation unit type |
Multi-pole rotating field type |
| Voltage Regulation Method |
Sine wave inverter type |
| frequency |
50Hz/60Hz (switchable) |
| Exchange |
| Rated Power |
3.8kVA/3.4kVA |
| Maximum power |
4.0kVA/3.6kVA |
| Rated voltage |
Single phase 100V |
| Rated Current |
38A/34A |
| Number of power outlets |
3 outlets |
| Direct current |
| Cigarette lighter DC rated voltage |
12V |
| DC Current Rating |
8.3A |
| Number of DC power outlets |
1 |
| USB |
| USB-A rated voltage |
– |
| USB-A rated current |
– |
| Number of USB-A power outlets |
– |
| Parallel/Series Connection |
| Parallel connection Rated output |
– |
| Rated voltage |
– |
| Rated Current |
– |
| Series connection Rated output (kVA) |
– |
| Rated voltage (V) |
– |
| Rated Current (A) |
– |
| engine |
| Engine Type |
Air-cooled 4-stroke single cylinder OHV |
| Total Displacement |
223cc |
| Engine oil |
SAE10W-30/10W-40 |
| Lubricating Oil Capacity |
0.6L |
| Spark plug |
F6RTC |
| fuel |
| fuel |
Low pressure LP gas (liquefied petroleum gas) |
| Continuous operation time |
1.11kg/h |
| Regular unleaded gasoline |
Tank capacity: 14.5L |
| Continuous operation time |
Approximately 7 to 27 hours |
| Noise level (7m) |
| 1/4 load |
Approximately 66 dB |
| 3/4 load |
– |
| Starting method |
| Recoil Start |
〇 |
| Push Start Switch |
– |
| Remote Start |
– |
| Protective Device |
| AC Overcurrent Protection |
〇 |
| AC Overheat Protection |
〇 |
| DC Overcurrent Protection |
〇 |
| DC Overheat Protection |
〇 |
